The Seals of Power, Part 2–Sealing Solutions for Green Energy

The power of the natural world is all around us. In the wind, the sun, the ocean, and in every living thing on the planet, energy is consumed and expended with every moment. Capturing even the tiniest fraction of that energy and converting it into electrical power for human consumption requires complex mechanical systems that are still being developed and perfected.

Most forms of green energy production require mechanical seals to operate efficiently and dependably in harsh and challenging environments. The power of nature is unlimited, but extracting viable payloads from the source inevitably requires robust machinery delivering prolonged, optimal performance with minimal maintenance and maximum efficiency.

Here are some of the ways mechanical seals being used in various forms of power production from renewable sources of energy:

Wind Power

Wind turbines use mechanical seals to prevent ingress of contaminants, prevent lubricant leakage, minimize the maintenance burden, and ensure equipment durability. These seals must withstand harsh environmental conditions, including high winds, temperature variations, and exposure to airborne contaminants.

Circumferential Seals are used in the main shaft bearings of wind turbines to provide a barrier between the rotating shaft and the stationary components, keeping lubricants in and contaminants out.

Labyrinth Seals are used in the gearbox to keep dirt and dust from entering. The name refers to the complex arrangement of closely placed fins that create a convoluted path for any contaminants to travel before reaching the gear mechanism.

Carbon Ring Seals are deployed in the pitch and yaw systems that control the orientation of the turbine blades. These highly durable seals create an effective barrier against moisture, dust and other environmental contaminants.

Lip Seals, or radial shaft seals, provide enduring protection against intruding contaminants for rotating components.

Floating Face Seals, or mechanical face seals, are used in the hub and bearing assemblies to keep lubricants in and contaminants out. Highly robust and durable,  floating face seals consist of two mating faces held tightly together by a spring-loaded mechanism.

Hydropower

Mechanical seals are used in hydropower plants to maintain crucial  pressure differentials and prevent water leakage, reduce friction and wear, and protect generators from water ingress. These seals must be robust and capable of withstanding the pressures associated with water turbines.

Turbine Shaft Seals keep water from leaking out of the turbine casing into the lower-pressure water outside. They maintain a watertight seal while permitting the shaft to turn freely.

Hydrodynamic Seals are perfect for the low-pressure applications of renewable energy generation. They function by using moving fluid to create a barrier between two moving parts. They are installed in hydraulic turbines and pumps to reduce friction and prevent leakage.

Labyrinth Seals are employed in hydropower turbines and gates to prevent water from leaking along rotating or moving shafts.

Pump Seals are essential for preventing water leakage along the shaft of the pump. They ensure that the pump operates efficiently by maintaining the pressure differential required for water to be transported from lower to higher elevations.

Single and Double Mechanical Seals are used in various components of hydropower systems, including pumps and turbines. They provide a reliable barrier against water leakage and can withstand high pressures and speeds. Double mechanical seals offer an additional layer of protection by incorporating two sets of sealing surfaces.

Cartridge Seals are pre-assembled units that are easy to install and replace, making them suitable for use in hydropower  applications where maintenance downtime needs to be minimized. They are commonly used in pumps and turbines to prevent water leakage and maintain operational efficiency.

Generator Shaft Seals are crucial for preventing water ingress into the generator housing, where sensitive electrical components are located. These seals help to maintain a dry environment within the generator, ensuring safe and reliable operation.

Geothermal Power

In geothermal power plants, mechanical seals are used to seal the wellhead to prevent the escape of geothermal fluids and to guard against abrasive elements and contaminant intrusion. They must be compatible with high-temperature, highly corrosive environments.

Labyrinth Seal features a complex arrangement of internal fins and teeth that are effective at preventing leakage and infiltration, even under high pressure. This makes the labyrinth seal very useful in geothermal power production where they are installed around in various components including steam turbines and pumps.

Carbon Ring Seals offer excellent resistance to high temperatures and corrosive environments, making them ideal for use in geothermal power production. In pumps, valves, and other components, carbon ring seals prevent fluid leakage and minimize wear caused by the abrasiveness inherent in geothermal fluids.

Floating Face Seals are effective at protecting wellheads, pumps, and turbines from the intrusion of abrasive fluids and other contaminants present in the contexts of geothermal power generation.

Turbine Shaft Seals are essential to geothermal power production, where they are installed around the rotating turbine shaft to prevent steam and fluid leakage and maintain critical pressure differential. .

Cartridge Seals are used throughout geothermal power plants to prevent leakage and maintain optimal performance of various components, including pumps and compressors. Pre-assembled cartridge seals are easily installed and removed, reducing the burden of maintenance and repairs.

Wave and Tidal Power

As in other forms of power generation, mechanical seals for wave and tidal energy plants are instrumental in maintaining pressure differentials, preventing fluid leaks, protecting systems against corrosion and contaminant intrusion, and generally contributing to overall system efficiency. The hydraulic systems involved in wave- and tide-driven power generation require watertight seals in order to function.

Circumferential Seals protect critical components like bearings, gearboxes, and hydraulic systems in the high-pressure, corrosive undersea environment.

Labyrinth Seals are instrumental in maintaining system efficiency and maintaining pressure differentials for wave and tidal power systems. They can be installed around turbine shafts, in gearboxes, and in hydraulic cylinders, where they minimize lubrication leakage and inhibit saltwater intrusion.

Carbon Ring Seals are valued for their high resistance to saltwater corrosion. In wave and tidal power plants, carbon ring seals are used in rotating components to prevent leakage and minimize wear for longer equipment life.

Floating Face Seals create an effective barrier against intrusion of saltwater, sand, and other undersea contaminants. They are installed in turbine hubs to maintain system integrity and prevent component failure.

Turbine Shaft Seals are essential for preventing water ingress along the turbine shaft in wave and tidal power generation systems. These seals help maintain pressure differentials and protect the turbine’s internal components from exposure to corrosive saltwater, ensuring long-term reliability and performance.

Cartridge Seals offer a convenient and reliable sealing solution for wave and tidal power generation equipment. They are pre-assembled units that are easy to install and replace, minimizing downtime during maintenance activities. Cartridge seals can be used in pumps, compressors, and other critical components to prevent fluid leakage and maintain system efficiency in marine environments.

Biomass Power

Mechanical seals are used in various ways throughout the multiple steps of processing required to turn biomass feedstock into electricity. Whether the process involves combustion, decomposition, or gasification, biomass fuel production generates liquid and gas matter that must be contained and transported. Mechanical seals make it possible to do this effectively and efficiently.

Pump Seals are essential to containing the biomass feedstock as it decomposes or is otherwise converted from raw materials, such as vegetation, sawdust, etc., into usable gaseous or liquid biofuel. Pump seals prevent leakage of the water and other process fluids, as well as the steam produced in processing. They also protect the feedstock from environmental contaminants and help prolong the life of processing equipment.

Cartridge Seals are used in the pumps that circulate cooling water, move heat transfer fluids, or handle other liquids. They are resistant to the highly abrasive qualities of much of the material processed into biofuel, and can withstand the high temperatures and pressures inherent in biomass fuel production. Additionally, cartridge seals are easy to install and maintain, making these systems easy to keep in optimum working order.

Stein’s extensive experience with gas turbines provides a solid technological foundation to provide seals for the green power industries.
